Steyr Sport 2016

Pistols


Specifications

action type: single-shot pistol for pellets


propellant: compressed air


calibre: 4,5 mm (.177)


length / height / width:350 / 148 / 50 mm


weight: 901 g


length of sight: 266 - 315 mm


front sight: moveable, rotable front sight (4,5 mm)


rear sight: rear sight 2 - 6 mm variable, depth 1 - 3 mm rotable


trigger pull: 500 g


trigger settings: first stage length & weight, second stage weight, trigger stop


          trigger blade adjustable: Trigger blade           adjustable In height and length, axially and           radially




Specifications

action type: single-shot pistol for pellets


propellant: compressed air


calibre: 4,5 mm (.177)


length / height / width: 400 / 148 / 50 mm


weight: 968 g


length of sight: 316 - 365 mm


front sight: moveable, rotable front sight (4,5 mm)


rear sight: rear sight 2 - 6 mm variable, depth 1 - 3 mm rotable


trigger pull: 500 g


trigger settings: first stage length & weight, second stage weight, trigger stop


          trigger blade adjustable: Trigger blade           adjustable In height and length, axially and           radially




NEW  EVO 10 E





Specifications

action type: rapid fire semi-auto pellet pistol


propellant: compressed air


calibre: 4,5 mm (.177)


Length / height / width: 398 / 148 / 50 mm


weight: 1.050 g


length of sight: 307 - 350 mm


front sight: moveable blade (4,5 mm)


rear sight: rear sight 2 - 6 mm variable, depth  1 - 3 mm


trigger pull: 450 - 1.050 g


trigger settings: first stage length, trigger stop, trigger pull


Trigger blade adjustable: in all directions




LP 50 Currently not in UK Supply



The 5 shot STEYR LP 5 has had a long and outstanding career. Now STEYR have developed the LP 5 into the LP 50. This pistol became even smoother and ensures the stability of an ideal competition weapon in any air pistol discipline.
Being a great 5 shot weapon for the training of any dynamic pistol disciplines, the LP 50 is even more useful!




Specifications

action type: single-shot pistol for pellets


propellant: compressed air


calibre: 4,5 mm (.177)


length / height / width:350 / 148 / 50 mm


height: 901 g


length of sight: 266 - 315 mm


front sight: moveable, rotable front sight (4,5 mm)


rear sight: rear sight 2 - 6 mm variable, depth 1 - 3 mm rotable


trigger pull: 500 g


trigger settings: first stage length & weight, second stage weight, trigger stop


          trigger blade adjustable: Trigger blade           adjustable In height and length, axially and           radially




NEW  EVO 10 E Compact

Specifications

action type: rapid fire semi-auto pellet pistol


propellant: compressed air


calibre: 4,5 mm (.177)


Length / height / width: 348 / 140 / 50 mm


weight: 983 g


length of sight: 257 - 300 mm


front sight: moveable blade (4,5 mm)


rear sight: rear sight 2 - 6 mm variable, depth  1 - 3 mm


trigger pull: 450 - 1.050 g


trigger settings: first stage length, trigger stop, trigger pull


Trigger blade adjustable: in all directions




LP 50 Compact Currently not in UK supply



Shorter sighting line:
The sight radius of the LP 10- and LP 50-Compact-models is more variable than the LP 2 Compact: Length of sight radius of LP 10 C is between 266 and 315 mm and the LP 50 C is between 257 and 300 mm. The distance between the rear and front sight is shorter by 50 mm compared to the standard models and shows a mor stable sight picture in relationship to the target. The steadier sight picture will increase confidence in young and old alike and allow them to concentrate on trigger release.

Lighter weight:
The lighter weight means that the young shooter is able to train for
longer periods to build stamina and technique.






Specifications

action type: Single-shot pistol for pellets


propellant: Compressed air


calibre: 4,5 mm (.177)


length / height / widht:400 / 148 / 50 mm


weight: 968 g


length of sight: 316 - 365 mm


front sight: moveable, rotable front sight (4,5 mm)


rear sight: rear sight 2 - 6 mm variable, depth 1 - 3 mm rotable


trigger pull: 500 g


trigger settings: first stage length & weight, second stage weight, trigger stop


          trigger blade adjustable: Trigger blade           adjustable In height and length, axially and           radially





NEW  EVO 10 Compact


Specifications

action type: single-shot pistol for pellets


propellant: compressed air


calibre: 4,5 mm (.177)


length / height / width:330 / 140 / 50 mm


weight: 780 g


length of sight: 268 - 298 mm


front sight: moveable blade (4,5 mm)


rear sight: rear sight 3,5 / 4 mm


trigger pull: 500 g


trigger settings: first stage length & weight, second stage weight, trigger stop


trigger blade adjustable: length 8 mm, rotates 30°



NEW EVO 10

The new evo 10 with mechanical trigger:






Specifications

action type: single-shot pistol for pellets


propellant: compressed air


calibre: 4,5 mm (.177)


length / height / width:
390 / 148 / 50 mm


weight: 905 g


length of sight: 311 - 335 mm


front sight: moveable blade (4,5 mm)


rear sight: rear sight 3,5 / 4 mm


trigger pull: 500 g


trigger settings: first stage length & weight, second stage weight, trigger stop


trigger blade adjustable: length 8 mm, rotates 30°


LP2 Compact

The basis of the STEYR air pistol range offers all the features of the appreciated, prominent quality of STEYR: nickel-plated barrels, anodized surfaces and a legendary precision!



LP2


The basis of the STEYR air pistol range offers all the features of the appreciated, preeminent quality of STEYR: nickel-plated barrels, anodized surfaces and a legendary precision!


The new evo 10 with mechanical trigger:







Highest technology in electronic!






Highest technology in electronic!
